220V DOB
Square DOB · Square 220V DOB module
Nebula Square
70 × 70 mm, 4.5W direct-220V square module. No SMPS needed.
- 220V DOB
- 4.5W
- 165° beam
View details
Direct 220V
2W · 120 lm · 170° beam · 220V AC
Ultra 220V
Ultra 220V LED Module
Wire straight to 220V mains — no power supply needed.
220VAC direct
2WPower
170°Beam angle
1 yrWarranty
- CE marked
- 1 year warranty
Direct 220V product — no SMPS needed. It carries mains voltage: have it installed by a qualified electrician and never mix it with 12V circuits.
Overview
Why Ultra 220V?
Ultra runs directly off 220V AC, so there's no SMPS to buy, mount or replace — ideal for quick installs and boards where there's no room for a power supply.
A PMMA lens spreads 120 lumens through a 170° beam from 2W. Copper wire, rainproof build, 50,000-hour rated life and cool 6500K white; 1-year warranty.
- Direct 220V AC — no SMPS needed
- Wide 170° beam with PMMA lens
- 120 lumens from 2W
- Rainproof · 50,000-hour life
- 6500K white
- 1-year warranty
Light colour options
- White6500K
Where to use it
Quick-install glow sign boardsBoards without room for an SMPSLight boxesShop-front signage
Specifications
| Input voltage | 220V AC (direct) |
|---|---|
| Size | 72 × 16 mm (9 mm high) |
| Power | 2W per module |
| Brightness | 120 lm per module |
| Beam angle | 170° |
| Lens | PMMA |
| Wire | Copper |
| Pack | 20 modules per string |
| Operating temperature | −20 °C to +80 °C |
| Rated life | 50,000 hours |
| Protection | Rainproof |
| Light colour | White, 6500K |
| Warranty | 1 year |
| Certification | CE |
Specifications as published in the BT GLO catalogue. Download the catalogue (PDF) or WhatsApp us for current stock and bulk pricing.
Pairs with
Complete the system
Products that work with Ultra 220V.
Direct 220V
Rigid Bars · Direct-220V rigid bar
Astra 220V
3 ft 12W rigid bar for direct 220V, 6500K white.
- 220V direct
- 3 ft bar
- No SMPS
View details
More LED Modules
Others in this range
New
LED Modules · Professional 3-LED module
2W Samsung
New 2W module: original Samsung LEDs, 185 lumens and a 5-year warranty.
- 2W
- 185 lm
- 5-yr warranty
View details
Double LED
LED Modules · Double-LED module
Vega
1.8W double-LED module with a 170° beam and a 2-year warranty.
- 1.8W
- 170° beam
- 2-yr warranty
View details
Samsung Korea
LED Modules · Samsung Korea LED module
Apollo
1.5W module with Samsung Korea LEDs, 120 lumens and a 2-year warranty.
- Samsung Korea
- 1.5W
- 2-yr warranty
View details
Sign calculator
Plan your board in seconds.
Enter your board size and depth — get the module count, spacing and the power supplies you need.
FAQ
Ultra 220V questions
Can't find your answer? Ask us directly — we're happy to help.
Do I need a power supply for Ultra 220V?
No. Ultra connects directly to 220V AC mains. Because it carries mains voltage, it must be installed by a qualified electrician with proper insulation and earthing.
Can I mix Ultra with 12V modules?
Never on the same circuit. 12V modules connected to 220V are destroyed instantly. Keep 220V and 12V runs completely separate and clearly labelled.
Can I connect 12V LED modules directly to 220V mains?
No. 12V DC products (2W Samsung, Vega, Apollo, Titan Eco, Mini, Astra DC and Astra Waterproof) must always run through a 12V SMPS. Connecting them to 220V destroys them instantly and is a fire and shock risk. Only Ultra 220V, Nebula Square and Astra 220V are made for direct mains.
Order Ultra 220V for your next job.
Share the quantity and delivery city — we'll reply with pricing and availability.
